Plant Protoplast Culture: Meaning, History and Principles

Let us make an in-depth study of the meaning, history and principles of plant protoplast culture.

What is a Protoplast?

It is known that each and every plant cell possesses a definite cellulosic cell wall and the protoplast lies within the cell wall except some reproductive cells and the free floating cells in some fruit juices like coconut water.

Therefore, protoplast of plant cell consists of plasma-lemma and everything contained within it.

But those of importance to plant protoplast culture are pro­duced experimentally by the removal of cell wall by either enzymatically or mechanical means from the artificially plasmolysed plant cells. Ex­perimentally produced protoplasts are known as isolated protoplasts.

According to Torrey and Landgren (1977) “the isolated protoplasts are the cells with their walls stripped off and removed from the prox­imity of their neighbouring cells”. Vasil (1980) defines that “the protoplast is a part of plant cell which lies within the cell wall and can be plas­molysed and which can be isolated by removing the cell wall by mechanical or enzymatic proce­dure”. Therefore, isolated protoplast is only a naked plant cell surrounded by plasma membra­ne—which is potentially capable of cell wall re­generation, cell division, growth and plant regen­eration in culture.

Brief Past History:

J. Klercker (1892):

First isolated proto­plast mechanically from plasmolyzed cell of wa­ter warrior (Stratiotes aloides). No attempt was made to culture them.

E. Kiister (1927):

In the fruits of several plants like Solatium nigram, Lycopersicon esculenium etc. the cell wall are hydrolysed during fruits ripening process so that free protoplasts and protoplasmic units are left. Kuster preferred such physiological method for isolating proto­plasts. No report of culture was available.

R. Chambers and K. Hofler (1931):

Were able to isolate few protoplasts by using thin slices of epidermis of onion bulb immersed in 1M sucrose until the protoplast shrunk away from their enclosing walls and then cutting sheets of epidermis with a sharp knife. Report of culture was not available.

E. C. Cocking (I960):

First reported the enzymatic method for isolation of protoplast in a large number from root tip cells of Lycopersicon esculentum by using a concentrated solution of cellulase enzyme, prepared from cultures of the fungus Myrothecium verrucaria to degrade cell wall.

I. Takebe, Y. Otsuki and S. Aoki (1968):

First employed the commercial preparation of cellulase and macerozyme sequentially (in two steps) for the isolation of mesophyll protoplast of tobacco.

J. B. Power and E. C. Cocking (1968):

Demonstrated first that the mixture of such two enzymes (cellulase + macerozyme) can be used simultaneously (one step method) for the isola­tion of protoplasts.

I. Takebe, G. Labib, G. Melchers (1971):

First reported the plant regeneration from isolated protoplast in Nicotiana tabacum.

P. S. Carlson, H. H. Smith, R. D. Dearing (1972):

First reported a somatic hy­brid in higher plants involving two different sex­ually compatible species of mesophyll protoplast (N. glauca x N. langsdorffi).

Different Sources of Plant Tissue and Their Condition for Protoplast Isolation:

Protoplast can be isolated either directly from the different parts of whole plant or indi­rectly from in vitro cultured tissue. Convenient and suitable materials are leaf, mesophyll and cells from liquid suspension cul­tures. Protoplast yield and viability are pro­foundly influenced by the growing conditions of plants serving leaf mesophyll sources.

The age of the plant and of the leaf and the prevailing conditions of light, photoperiod, humidity, tem­perature, nutrition and watering are contribut­ing factors. Cell suspension cultures may provide a more reliable source for obtaining consistent qua­lity protoplasts. It is necessary, however, to es­tablish and maintain the cells at maximum growth rates and utilize the cell at the early log phase.

Principles of Protoplast Culture:

The basic principle of protoplast culture is the aseptic isolation of large number of intact living protoplasts removing their cell wall and cultures them on a suitable nutrient medium for their requisite growth and development. Protoplast can be isolated from varieties of plant tissues. Convenient and suitable materials are leaf mesophyll and cells from liquid suspension culture. Protoplast yield and viabil­ity are greatly influenced by the growing condi­tion of the plant as well as the cells.

The essential step of the isolation of proto­plast is the removal of the cell wall without dam­aging the cell or protoplasts. The plant cell is an osmotic system. The cell wall exerts the inward pressure upon the enclosed protoplasts. Like­wise, the protoplast also puts equal and oppo­site pressure upon the cell wall. Thus, both the pressures are balanced.

Now if the cell wall is re­moved, the balanced pressures will be disturbed. As a result, the outward pressure of protoplast will be greater and at the same time in absence of cell wall, irresistible expansion of protoplast takes place due to huge inflow of water from the external medium. Greater outward pressure and the expansion of protoplast cause it to burst.

So, the isolated protoplast is an osmotically frag­ile structure at its nascent stage. Therefore, if the cell wall is to be removed to isolate proto­plast, the cell or tissue must be placed in a hy­pertonic solution of a metabolically inert sugar such as mannitol at higher concentration (13%) to plasmolysis the cell away from the cell wall (Fig 12.2).

Mannitol, an alcoholic sugar, is easily transported across the plasmodesmata, provides a stable osmotic environment for the protoplasts and prevents the usual expansion and bursting of protoplast even after loss of cell wall. That is why, this hypertonic solution is known as os­motic stabilizer or plasmolyticum or osmolyticum.

Once the cells are stabilized in such a man­ner by plasmolysis the protoplasts are released from the containing cell wall either mechanically or enzymatically. Mechanical isolation (Fig 12.3) involves breaking open each cell compartment to liberate the protoplast. This operation can be done carefully on small pieces of tissue un­der a microscope using a micro-scalpel.

But very few protoplasts are obtained for a lot of time and effort. Large-scale attempts at mechani­cal isolation involves the disrupting tissue with fine stainless steel-bristled brush. This process may liberate more protoplasts with less efforts, but the percentage of yield of intact protoplasts is still very low.

A considerably more efficient way of liberating the protoplasts is to digest the cell walls away around them, using cell wall de­grading enzymes such as cellulase, hemicellulose, pectinase or macerozyme etc. These enzymes are isolated from fungi and available commercially (Table 12.1).

Period of treatment and concentration of enzymes are the critical factors and both factors should be standardized for particular plant tis­sue. Intact tissue can be incubated with a pecti­nase or macerozyme solution which will dissolve the middle lamella between the cells and so sep­arate them.

Subsequent treatment with cellu­lase will digest away the cellulosic layer of the cell wall. This process is known as sequential enzyme treatment or two step method as op­posed to a mixed enzyme treatment (one step method) in which both cellulase and pectinase or macerozyme are mixed so that the entire wall is broken down in a single operation (Fig. 12.4).

The isolated protoplasts can be cultured ei­ther static liquid or agarified medium. The pro­toplast media consist of mineral salts, vitamins, carbon sources and plant growth hormones as well as osmotic stabilizers and possibly organic nitrogen sources, coconut milk and organic acids.

In culture protoplast can reform a new cell wall around them. Once the wall is formed, the proto­plast becomes a cell. The cells from protoplasts subsequently enter cell division which is followed by the formation of callus and cell cultures. Such callus also retain the capacity for morphogenesis and plant regeneration. A brief list of plant regeneration from plant protoplast culture is given below (Table 12.2).
